22 Small form factor pluggable transceivers
Table 3
SFP models with DDI capability
Model Product number Description
1000BASE-T (RJ-45) AA1419043-E6 CAT5 UTP, up to 100 m. Note that
because the 1000BASE-T device is
all electrical, there is no need for DDI
support.
1000BASE-BX (LC type) AA1419069-E6,
AA1419070-E6 Bidirectional 1310 nm and 1490 nm, up
to 10 km
For specifications for these SFPs, see "SFP specifications" (page 33) .
Installing an SFP
Install an SFP to provide an interface between the switch and the network
cable.
Installing an SFP takes about three minutes.
WARNING
Risk of eye injury by laser
Fiber optic equipment can emit laser or infrared light that can
injure your eyes. Never look into an optical fiber or connector port.
Always assume that fiber optic cables are connected to a light
source.
Prerequisites
• Verify that the SFP is the correct model for your network configuration.
Procedure steps
Step Action
1 Remove the SFP from its protective packaging.
2 Grasp the SFP between your thumb and forefinger.
3 As shown in the following figure, insert the device into the slot on
the module.
Apply a light pressure to the device until it clicks and locks into
position.
