34 SFP specifications
Figure 5
SFP label
General SFP specifications
The following table describes general SFP specifications.
Table 5
General SFP specifications
Parameter Description
Dimensions (H x W x D) 13.4 x 8.50 x 56.4 millimeters (mm)
0.53 x 0.33 x 2.22 inches (in.) unless otherwise
stated
Operating temperature -5 to 85C for RoHS -E6 models
0 to 60C for RoHS -E5 models
Storage temperature -40 to 85C
Maximum supply current 300 mA unless otherwise stated
Maximum power consumption 1.0 W unless otherwise stated
1000BASE-T SFP specifications
The 1000BASE-T SFP provides Gigabit Ethernet connectivity using a single
eight-pin RJ-45 connector. The 1000BASE-T SFP only operates at 1 gigabit
per second (1 Gbit/s) and does not support 100BASE-T or 10BASE-T
interfaces. The part number for this model is AA1419043-E6.
