1000BASE-XD CWDM SFP specifications 37
Table 9
IEEE 802.3z 1000BASE-LX SFP specifications
Parameter Specifications
Connectors Duplex LC
Cabling • 50 micrometer (µm) multimode fiber (MMF)
• 62.5 µm multimode fiber
• 9 µm single mode fiber (SMF)
Distance • Up to 550 meters (m) using MMF
• Up to 10 kilometers (km) using SMF
Wavelength 1310 nm
Link optical power budget 11.5 dB
Transmitter characteristics
Launch power -9.5 to -3.0 dBm
Receiver characteristics
Receiver sensitivity -20 dBm
Maximum input power -3.0 dBm
1000BASE-XD CWDM SFP specifications
The part numbers of the 40 km models range from AA1419025-E5 to
AA1419032-E5.
CAUTION
Risk of equipment damage
For the 40 km CWDM SFPs, a minimum attenuation of 4 dB must
be present between the transmitter and receiver. To avoid receiver
saturation, you must insert a minimum attenuation of 4 dB when
you test the CWDM SFP in loopback mode, or use short runs of
fiber with no intermediate CWDM OADM or CWDM OMUX.
Table 10
1000BASE-XD CWDM (40 km) SFP specifications
Parameter Specifications
Connectors Duplex LC
Cabling SMF, 9 µm
Data rate 1.0 Gbit/s
Line rate (8B/10B code) 1.25 Gbit/s
Operating temperature range 0 to 60C
Link optical power budget 17 dB
Nortel Ethernet Routing Switch 8300
Installation — SFPs and XFPs
NN46200-307 01.04 Standard
4.0 14 February 2008
