42 XFP specifications
Figure 7
XFP label
General XFP specifications
The following table describes general XFP specifications.
Table 13
General XFP specifications
Parameter Specifications
Dimensions (H x W x D) 0.49 x 0.72 x 2.79 inches (in.)
12.5 x 18.35 x 71.1 millimeters (mm)
Connectors LC ultra physical contact (UPC)
Storage temperature -40 to 85C
Operating temperature 0 to 70C
10GBASE-SR XFP specifications
The 10GBASE-SR XFP provides 10 GbE service at 850 nm.
The following table lists the specifications for the 10GBASE-SR XFP. The
part number of this XFP is AA1403005-E5.
For more information about the 10GBASE-SR XFP, including test and
measurement information, see the IEEE 802.3ae standard.
CAUTION
Risk of equipment damage
To prevent damage to the optical receiver, ensure that at least 1 dB
of attenuation is present between the transmit and receive ports.
Nortel Ethernet Routing Switch 8300
Installation — SFPs and XFPs
NN46200-307 01.04 Standard
4.0 14 February 2008
Copyright © 2008, Nortel Networks
.
