28 10 Gigabit small form factor pluggable transceivers
—End—
Procedure job aid: XFP models
XFPs are hot-swappable input/output enhancement components designed
for use with Nortel products to allow 10 Gigabit Ethernet ports to link with
other 10 Gigabit Ethernet ports.
All Nortel XFPs use LC connectors (Lucent optical connectors) to provide
precision keying and low interface losses.
The following table lists and describes the Nortel XFP models. For
specifications for these XFPs, see
"XFP specifications" (page 41) .
Table 4
XFP models
Model number Product number Description
10GBASE-SR AA1403005-E5 850 nanometers (nm). The range is up to:
• 22 m using 62.5 micrometer ( µ m), 160
megaHertz times km (MHz-km) MMF
• 33 m using 62.5 µ m, 200 MHz-km MMF
• 66 m using 62.5 µ m, 500 MHz-km MMF
• 82 m using 50 µ m, 500 MHz-km MMF
• 300 m using 50 µ m, 2000 MHz-km MMF
10GBASE-LR/LW AA1403001-E5 1310 nm SMF. The range is up to 10 km.
10GBASE-ER/EW AA1403003-E5 1550 nm SMF. The range is up to 40 km.
10GBASE-ZR/ZW AA1403006-E5 1550 nm SMF. The range is up to 80 km.
Installing an XFP
Install an XFP to provide a 10 Gigabit Ethernet interface between the switch
and other network devices.
Installing an XFP takes about three minutes.
WARNING
Risk of eye injury by laser
Fiber optic equipment can emit laser or infrared light that can
injure your eyes. Never look into an optical fiber or connector port.
Always assume that fiber optic cables are connected to a light
source.
Nortel Ethernet Routing Switch 8300
Installation — SFPs and XFPs
NN46200-307 01.04 Standard
4.0 14 February 2008
Copyright © 2008, Nortel Networks
.
