1000BASE-SX (LC) SFP specifications 35
ATTENTION
You must disable autonegotiation before operating the 1000BASE-T SFP.
By default, SFPs inserted into certain product-specific modules are set for
Autonegotiation = True.
The maximum current requirement of the SFP is 375 milliamperes (mA) at
5 volts (V).
The following table describes the 1000BASE-T SFP specifications.
Table 6
IEEE 802.3z 1000BASE-T SFP specifications
Parameter Specifications
Standards IEEE 802.3z, IEEE 802.3ab
Connectors RJ-45
Cabling CAT5E or better UTP
Distance Up to 100 m
1000BASE-SX (LC) SFP specifications
The 1000BASE-SX SFP provides 1000BASE-SX Gigabit Ethernet
connectivity at 850 nm using multimode optical fiber. This SFP supports
full-duplex operation only. The part number for this model is AA1419013-E5.
The following table describes standards, connectors, cabling, and distance
for the 1000BASE-SX SFP.
Table 7
IEEE 802.3z 1000BASE-SX (LC) SFP specifications
Parameter Specifications
Connectors Duplex LC
Cabling • 62.5 µm MMF optic cable
• 50 µm MMF optic cable
Distance • Up to 275 m using 62.5 µm MMF optic cable
• Up to 550 m using 50 µm MMF optic cable
Wavelength 850 nanometers (nm)
Link optical power budget 7.0 deciBels (dB)
Transmitter characteristics
Launch power -10 to -4.0 deciBels referenced to 1 milliwatt
(dBm)
Nortel Ethernet Routing Switch 8300
Installation — SFPs and XFPs
NN46200-307 01.04 Standard
4.0 14 February 2008
