10GBASE-ER/EW XFP specifications 45
Parameter Specifications
RIN
12
OMA (maximum) -128 dB/Hz
Maximum optical return loss tolerance -12 dB
Maximum transmitter reflectance -12 dB
Receiver characteristics
Line rate (nominal) 10GBASE-LR 10.3125 Gbit/s ± 100 ppm
10GBASE-LW 9.95328 Gbit/s ± 100 ppm
Average receive power for BER 10 -12 -14.4 dBm to 0.5 dBm
Maximum average receive power for damage 1.5 dBm
Maximum receiver sensitivity in OMA -12.6 dBm
Maximum receiver reflectance -12 dB
Stressed receiver sensitivity in OMA -10.3 dBm
Receiver electrical 3 dB upper cutoff frequency 12.3 GHz
Examples of an OFF transmitter are: no power supplied to the PDM, laser
shutdown for safety conditions, activation of a PMD_global_transmit_disable
or other optional transmitter shut down condition
10GBASE-ER/EW XFP specifications
The following table lists the transmitter specifications for the
10GBASE-ER/EW XFP. The reach for this XFP is up to 40 km at a
wavelength of 1550 nm. The part number of this XFP is AA1403003-E5.
For more information about the 10GBASE-EX XFP, including test and
measurement information and more specifications, see the IEEE 802.3ae
standard.
ATTENTION
You can configure the XFP to operate in either LAN (Ethernet) or WAN (SONET)
mode, depending on the module (8683XLR is a LAN-only module, and 8683XZR
is a LAN/ WAN module). Model numbers ending in R denote a LAN interface;
model numbers ending in W denote a WAN interface.
Table 16
IEEE 802.3ae 10GBASE-ER/EW XFP specifications
Parameter Specifications
Line rate (nominal) 10GBASE-ER 10.3125 Gbit/s ±100 ppm
10GBASE-EW 9.95328 Gbit/s ±20 ppm
MTBF 675 000 hours
Center wavelength range 1530 to 1565 nm; nominal 1550 nm
