Installing the server and connecting the peripheral devices

Standard 1.0

70

CallPilot

To connect the 1001rp AC server to power

1 Plug the server’s AC power cord into the server’s rear panel.

2 Plug the other end of the server’s AC power cord into a properly

grounded power outlet or power bar.

.

CAUTION

Risk of personal injury and hardware failure

The power outlets that are used by the CallPilot server and its
peripheral devices must be connected to the same single-point
ground reference as the one used by the Meridian 1 switch or
Succession CSE 1000 system. If this requirement is not met,
power transients can cause personal injury and/or hardware
failure.
