May 2003 1001rp server description
Part 2: 1001rp Server Hardware Installation 13
Overhead view of empty server showing PCI and ISA
connectors
The following diagram shows the location of the PCI, SBC, and ISA
connectors inside the server. The view in the diagram is from the rear of the
server. For slot assignments, see “Slot assignments” on page 14. You must
be able to identify slot locations for later steps in the CallPilot installation.
G101740
PCI
connectors
SBC
connector
ISA
connectors
