May 2003 Preparing for installation
Part 2: 1001rp Server Hardware Installation 27
6 For a DC-powered server, set up the DC power source (see
page 43). ❒
7 Place the 1001rp server in the chosen location (see page 54). ❒
8 Replace the front bezel (see page 34). ❒
9 Set the DIP switches on the modem (see page 57). ❒
10 Connect the 1001rp server and devices as follows:
„ Connect the monitor, keyboard, and mouse (see page 59). ❒
„ Connect the modem (see page 60). ❒
„ Connect the 1001rp server to the ELAN hub (Meridian 1 or
Succession CSE 1000 only) (see page 62). ❒
„ Connect the 1001rp server to the CLAN hub (optional) (see
page 64). ❒
„ Install the software feature key adapter (see page 66). ❒
„ Connect the power cords for all devices, and then power
them up. ❒
11 Start the 1001rp server (see page 68). ❒
Step Description Check
