Preparing for installation Standard 1.0
34 CallPilot
To replace the front bezel after installation is complete
When the CallPilot server installation is complete and the server is in its
final location, replace the front bezel.
1 Align the front bezel with the ball studs located at each faceplate corner.
See the diagram below:
2 Apply pressure evenly until the bezel snaps onto each ball stud.
3 Close and lock the double doors of the front bezel.
G101734
Clips inside
front bezel
