1001rp server description
Part 2: 1001rp Server Hardware Installation
15
Slot 3
BRD03
Not used
Not used
Slot 4
BRD04
Not used
Not used
Slot 5
BRD05
Not used
Not used
Slot 6
BRD06
Not used
Not used
Slot 7
BRD07
Not used
Not used
Slot 8
BRD08
Single Board Computer
Single Board Computer
Slot 9
BRD09
Reserved for COM1 and
COM2 I/O bracket
Reserved for COM1 and
COM2 I/O bracket
Slot 10
BRD10
ELAN Network card
ELAN Network card
Slot 11
BRD11
CLAN Network card
CLAN Network card
Slot 12
b
BRD12
MPB16-4 board #1
MPB16-4 board #1
Slot 13
BRD13
MPB16-4 board #2
(optional)
MPB16-4 board #2
(optional)
Slot 14
BRD14
Not used
Not used
Slot 15
BRD15
Not used
Not used
Slot 16
BRD16
Not used
Not used
Slot 17
BRD17
Not used
Not used
Slot 18
BRD18
Not used
Not used
Slot 19
BRD19
VGA card (monitor
connection)
VGA card (monitor
connection)
Slot
number
CallPilot-
assigned board
label
a
Meridian 1
Succession CSE 1000
