NETGEAR ADSL Firewall Router DG834 - Manual (Page 59)

Reference Manual for the ADSL Firewall Router DG834
Protecting Your Network 4-15
202-10005-05, June 2005
2. Select the Schedule link of the Security menu to display menu shown above in the Schedule
Services menu .
3. To block Internet services based on a schedule, select Every Day or select one or more days. If
you want to limit access completely for the selected days, select All Day. Otherwise, to limit
access during certain times for the selected days, enter Start Blocking and End Blocking times.
Note: Enter the values in 24-hour time format. For example, 10:30 am would be 10 hours and
30 minutes and 10:30 pm would be 22 hours and 30 minutes. If you set the start time after the
end time, the schedule will be effective through midnight the next day.
4. Click Apply to save your changes.
