Reference Manual for the ADSL Firewall Router DG834

Virtual Private Networking (Advanced Feature)

7-41

202-10005-05, June 2005

This setting applies to both IKE and IPSec SAs. When configuring the remote endpoint to match
this setting, you may have to specify the "Key Group" used. For this device, the "Key Group" is
the same as the "DH Group" setting in the IKE section.

Example of Using Auto Policy

Figure 7-42: Gateway-to-Gateway VPN Tunnel

1.

Set the LAN IPs on each DG834 to different subnets and configure each properly for the
Internet. The following settings are assumed for this example:

A

B

VPN Tunnel

DG834 VPN Firewall

DG834 VPN Firewall

PCs

PCs

192.168.0.1

192.168.3.1

14.15.16.17

22.23.24.25
