Reference Manual for the ADSL Firewall Router DG834
7-22 Virtual Private Networking (Advanced Feature)
202-10005-05, June 2005
Follow this procedure to configure a gateway-to-gateway VPN tunnel using the VPN Wizard.
1. Log in to the DG834 on LAN A at its default LAN address of http://192.168.0.1 with its
default user name of admin and password of password . Click the VPN Wizard link in the
main menu to display this screen. Click Next to proceed.
Figure 7-21: VPN Wizard Start Screen
2. Fill in the Connection Name and the pre-shared key, select the type of target end point, and
click Next to proceed.
Figure 7-22: Connection Name and Remote IP Type
Enter the new Connection Name:
(e.g., GtoG)
Enter the pre-shared key:
(e.g., 12345678)
Select the radio button:
A remote VPN Gateway
