Te c h n i c a l S p e c i f i c a t i o n s
B-9
P
h
ili
ps
Me
dic
a
l
Sy
s
tem
s
B
(Optional) M3873A/M3874A FR2+ ECG assessment
module
category nominal specifications
Application For use with the FR2+ M3860A with ECG display enabled and running version
1.5 software or higher (denoted by FR2+ on the front panel or rear label).
Length and Weight 100 inches (182 cm); ≤ 1 lb. (2.2 kg).
Operating Temperature and
Humidity 32° to 122° F (0° to 50° C);
0% to 95% relative humidity (non-condensing).
Storage Temperature and
Humidity 32° to 109° F (0° to 43° C).
0% to 75% relative humidity (non-condensing).
Patient Lead Wire
Designation M3873A (AAMI): M3874A (IEC):
positive lead
− red
positive lead
− green
negative lead
− white
negative lead
− red
reference lead − black. reference lead − yellow
Typical (Lead II) Connection Lead II vectors:
positive
− left leg
negative
− right arm
reference − left arm.
Other limb vectors can be obtained by different electrode positions.
Battery Type 3 V, 1 Ah, poly-carbonmonofluoride lithium (LiCFx). Non-replaceable disposable
primary cell.
Service Life Typically, 5 years.
Performance with FR2+
Defibrillator Meets environmental specifications cited for FR2+ Defibrillator on page B1
through B2.
