Te c h n i c a l S p e c i f i c a t i o n s
B-5
P
h
ili
ps
Me
dic
a
l
Sy
s
tem
s
B
Display
Controls and indicators
Pacemaker Detection On detection of a pacemaker (in advanced mode or with M3873A/M3874A FR2+
ECG assessment module), provides screen display of
PACEMAKER DETECTED
alert. M3860A includes pacemaker artifact in ECG display. In both models,
pacemaker artifact is removed from the signal for rhythm analysis.
category nominal specifications
category nominal specifications
Monitored ECG Lead ECG information is received from adult defibrillator pads in anterior-anterior (Lead
II) position or from FR2 infant/child reduced-energy defibrillator pads in
anterior-posterior position. (Displayed on M3860A only.)
ECG information can also be displayed in the M3860A using the FR2+ ECG
assessment module.
N O T E : The ECG display provided by the FR2+ Defibrillator is not is not
intended to provide diagnostic or ST segment interpretation.
Display Range
(M3860A only) Differential: ±2 mV full scale, nominal.
Screen Type High-resolution liquid crystal display (LCD) with backlight.
Screen Dimensions 2.8" wide x 2.3" high (70 mm x 58 mm).
Sweep Speed
(M3860A only) 23 mm/s nominal.
ECG Display 3 second-segments displayed (M3860A only).
Frequency Response
(Bandwidth) Nondiagnostic rhythm monitor 1 Hz to 20 Hz (-3 dB), nominal.
Sensitivity 1.16 cm/mV, nominal.
Heart Rate Displayed
(Normal Sinus Rhythm) 30 to 300 bpm, updated each analysis period. Displayed (M3860A only) during
monitoring and advanced modes.
category nominal specifications
LCD Screen High-resolution, backlighted LCD screen, displays text messages and (model
M3860A only) ECG.
