1. Network Management Specification
8000-A2-GB30-00 June 2003 63
7.1.2.1.11 entPhysicalSerialNum
The vendor-specific serial number string for the physical entity. Valid Object Value(s):
The following table shows the entPhysicalSerialNum identified for the entities supported.
7.1.2.1.12 entPhysicalMfgName
The name of the manufacturer of this physical component. The preferred value is the
manufacturer name string actually printed on the component itself (if present).Note that
comparisons between instances of the entPhysicalModelName, entPhysicalFirmwareRev,
entPhysicalSoftwareRev, and the entPhysicalSerialNum objects, are only meaningful
amongst entPhysicalEntries with the same value of entPhysicalMfgName. If the
manufacturer name string associated with the physical component is unknown to the agent,
then this object will contain a zero-length string.
Valid Object Value(s):
Console port zero-length-string
Ethernet Mgmt port zero-length-string
Temp Sensor zero-length-string
Fan zero-length-string
PowerSupply zero-length-string
Management Plane PLD A String with the currently running Software Revision Level.
Table 1-70. entPhysicalSerialNum
Entity entPhysicalSerialNum
Chassis zero-length-string
Container zero-length-string
Module A String with the Serial Number of the entity card.
Splitter card zero-length-string
DSL Port zero-length-string
T1/E1 port zero-length-string
OC3 port zero-length-string
Console port zero-length-string
Ethernet Mgmt port zero-length-string
Temp Sensor zero-length-string
Fan zero-length-string
PowerSupply zero-length-string
Management Plane PLD zero-length-string
Table 1-69. entPhysicalFirmwareRev (2 of 2)
Entity entPhysicalFirmwareRev
