1. Network Management Specification
8000-A2-GB30-00 June 2003 23
4.1.5 “ifSpeed” Object (ifEntry 5)
This object provides the interfaces’s current bandwidth in bits per second. The value of this
object for each interface will be specified as follows:
4.1.6 “ifPhysAddress” Object (ifEntry 6)
This object is used to specify the interface’s address at its protocol sub-layer. The interface’s
media-specific MIB must define the bit and byte ordering and format of the value contained
by this object. For the GranDSLAM 3.0 interfaces, this object should only contain the
ethernet address (MAC Address) of the unit. All other interfaces are in blank.
4.1.7 “ifAdminStatus” Object (ifEntry 7)
This object is used to specify the desired state (configuration) of the interface. When the
GranDSLAM 3.0 initializes, all physical interfaces start with ifAdminStatus in the up(1)
state. As a result of either explicit management action or per configuration ifAdminStatus
is changed to down(2). The ifAdminStatus values which may be assigned to each interface
after initialization are listed in the following table:
Table 1-10. ifSpeed
Interface ifSpeed
AAL5 0
ATMUP 155000000
DSL 16000000
DSLATM 16000000
DSLChan 16000000
E1 2048000
ETH 100000000
IMA [1544000..8*2048000]
SONET 155000000
SONETPath 155000000
T1 1544000
