1. Network Management Specification
8000-A2-GB30-00 June 2003 57
Valid Object Value(s):
a. Refers to the sysDescr in the MIB-II’s System Group for clarification on
Company Name.
b. n is the unit number that ranges between 1..8
c. x is the sensor number that ranges between 1..3
d. y is the fan number that ranges between 1..1
e. z is the power supply number that ranges between 1..2
7.1.2.1.3 entPhysicalVendorType
An indication of the vendor-specific hardware type of the physical entity.
Valid Object Value(s):
The following is the OID tree for the different entities supported.
Company Enterprise.1.14.9.14.5 (sme-chassis)
.1 sme-chassis-8820
.2 sme-chassis-8620
Company Enterprise.1.14.9.14.7 (sme-container)
Company Enterprise.1.14.9.14.1 (sme-scp-cards)
.1 sme-scp-8412-card (SCP w/OC3/STM1
MM ATM Uplink)
.2 sme-scp-8413-card (SCP w/OC3/STM1
SM int ATM Uplink)
Table 1-61. entPhysicalDescr
Entity Description
Chassis sysDescr as described in the MIB-II’s System Group.
Container "Paradyne DSLAM Slot x", Where x=1..20
Splitter card Paradyne DSLAM ; Splitter Module; Unit n
DSL Port ifDescr from Interfaces group (Section 4 )
T1/E1 port ifDescr from Interfaces group (Section 4 )
OC3 port ifDescr from Interfaces group (Section 4 )
Console port Console port
Ethernet Mgmt port ifDescr from Interfaces group (Section 4 )
Temp Sensor Temperature Sensor #x c ; Unit n
Fan Fan #y d .; Unit n
Power Supply Power Supply #z e .; Unit n
Management Plane PLD Management Plane PLD; Unit n
