1. Network Management Specification
62 June 2003 8000-A2-GB30-00
The following table shows the entPhysicalHardwareRev defined for each entity.
7.1.2.1.9 entPhysicalSoftwareRev:
The vendor-specific software revision string for the physical entity. If no specific firmware
programs are associated with the physical component, or this information is unknown to the
agent, then this object will contain a zero-length string. For the GranDSLAM 3.0 units, this
object will always return a zero-length string.
7.1.2.1.10 entPhysicalFirmwareRev
The vendor-specific software revision string for the physical entity.
Valid Object Value(s):
The following table shows the entPhysicalFirmwareRev assigned for the entities.
Table 1-68. entPhysicalHardwareRev
Entity entPhysicalHardwareRev
Chassis zero-length-string
Container zero-length-string
Module String containing the Revision Number of the CCA
Splitter card String containing the Revision Number of the CCA
DSL Port zero-length-string
T1/E1 port zero-length-string
OC3 port zero-length-string
Console port zero-length-string
Ethernet Mgmt port zero-length-string
Temp Sensor zero-length-string
Fan zero-length-string
PowerSupply zero-length-string
Management Plane PLD zero-length-string
Table 1-69. entPhysicalFirmwareRev (1 of 2)
Entity entPhysicalFirmwareRev
Chassis zero-length-string
Container zero-length-string
Module A String with the currently Firmware running in this module.
Splitter card zero-length-string
DSL Port A String reflecting the DSP revisions
T1/E1 port zero-length-string
OC3 port zero-length-string
