Problem Solution
Picture is displayed but it is • Adjust the Position of Analog Input Adjust if necessary (see
shifted to the right (or left) Section 5.1.3 )
• Ensure that the Image Position (see Section 5.2.6 ) is set to
the center of your screen (0,0)
• When output is analogue RGB, check horizontal sync
polarity is correctly set for your display (See Section 7.7 )
Objects in the image appear • Ensure that the Screen Shape (see Section 5.3.4 ) is set
to be too tall or too wide correctly.
• Ensure that the Image Aspect Ratio (see Section 5.2.4 ) is
set correctly.
• Ensure that the aspect ratio setting of your display device
is 16:9 in the setup menu of all source devices that support
this feature (DVD players, satellite receivers, etc), even if
the screen is not 16:9
Crystalio II VPS3800 (PRO) owners, please refer to the separate Crystalio II Media Player
Owners Guide for Media Player troubleshooting.
81
