Page 48
When the
action button is pressed, the OSD turns to the following page:
• You can define names for each output profile to help with identification
• Maximum number of characters in the text box is 20
• Clear the name by pressing the
action button
5.4
AUDIO SUB-MENU
The Audio sub-menu consists of all options related to the audio features of Crystalio II.
• Crystalio II has 3 audio output ports:
• 1 digital coaxial audio output
• 1 digital optical audio output
• 1 pair of analog stereo audio outputs (Left and Right channels)
• Audio output can also be embedded in the HDMI output ports
) are routed to all audio output ports (with delays, see
• The analog audio output port is active only when the audio input is either analog or
digital uncompressed format (e.g. PCM)
* Except when Advanced option Picture In Picture/Picture By Picture, or Secondary Passthru is ON. See
details
48
