Default positions for Switches SW1-SW8 are shown in the table on the
following page. Descriptions of each switch follow the table.
Switches SW1, SW2, and SW3
Use Switches SW1, SW2 and SW3 to set the DTE data rate. Each set-
ting represents an nx56/nx64 setting.
Switch SW4: Line Framing and Coding
Use Switch SW4 to control the Network Line Framing and Coding
Options. Set these options to be the same as the Line Framing and Cod-
ing Options given to you by your Service Provider. If you are using two
Model 2710s together as short range modems, set both units identically.
SWITCH SET SUMMARY TABLE
Position Function Factory Default
Selected
Option
SW1
SW2
SW3 Data Rate
Data Rate
Data Rate On
On
On
1.536 Mbps
(DTE Rate)
SW4 Framing & Coding Off ESF/B8ZS
SW5 DS Zero Rate On 64 kbps
SW6 Clock Mode Off Network
SW7
SW8 Line Build Out
Line Build Out Off
Off
0dB
SW1 SW2 SW3 Speed
OFF OFF OFF Clear Channel (Unframed)
ON OFF OFF 112kbps/128kbps
OFF ON OFF 224kbps/256kbps
ON ON OFF 336kbps/384kbps
OFF OFF ON 448kbps/512kbps
ON OFF ON 672kbps/768kbps
OFF ON ON 896kbps/1024kbps
ON ON ON 1344kbps/1536kbps
SW4 Line Framing & Coding
ON ESF/B8ZS
OFF D4/AMI
