Users Manual Model 545™
Printer Operation / Adjustments
• 25
Threading Diagram
• Open the hinged cover to the printer and thread the fabric through the splice /
fabric out sensor (B drawing two), the active unwind, the barrel rollers, the head
guards (A drawing two), the feed module, the knife, and then the stacker as
shown.
FEED ROLL
NIP ROLL
2/0 AND 1/0 THREADING PATH
