Panasonic WJ-SX650 - Manual (Page 23)

23
■ Basic System Connections
The following is a connection example to use one unit.
This unit x 1, camera x 30, monitor x 16, and recorder x 2
Video input board
Expansion slot
Video output board
A B
1 3 2 4 6 5 7 9 8 0
SYSTEM CONTROLLER A B
1 3 2 4 6 5 7 9 8 0
SYSTEM CONTROLLER
SERIAL
DATA
DATA
CAMERA IN
CAMERA IN
CAMERA IN
MONITOR OUT
MONITOR OUT
MONITOR
OUT
Recorder
Recorder
~
~
~
PC (WJ-SX650 Series
Administrator Console)
7 8
ON
6 1 2 3 4 5
7 8 6 1 2 3 4 5
7 8 6 1 2 3 4 5
7 8
ON
6 1 2 3 4 5
Camera 1 to 30
Monitor 1 to 16
VIDEO OUT (Loop-thru output)
(#7: ON)
(#8: OFF)
(#7: OFF)
(#8: OFF)
MODE switches
MODE switches
MODE switches
WV-CU950/650
WV-CU360C/CJ
Terminal mode,
Line termination: ON
