Perle 833IS User Guide 75
Chapter 6: Configuring the Interfaces
About Configuring the Interfaces
In this chapter, you will read about:
■ Overview of Interface Configuration
■ Interface selection screen
■ Configuring the Ethernet LAN interface
■ Configuring the Token Ring LAN interface
■ Configuring the ISDN BRI U interface
■ Configuring the ISDN BRI S/T interface
■ Configuring the PerleDSP Modem interface
Overview
The 833IS has been designed to provide a highly integrated platform for remote
access. Depending on your specific needs, the 833IS can support a variety of
specific interfaces. The following is a list of the interface currently supported by the
833IS product family. Please note that not all of the interfaces listed below will
necessarily be present on your 833IS unit.
LAN Interface
■ 10 Mbps Ethernet via RJ-45 connector
■ 100 Mbps Ethernet via RJ-45 connector
■ 4 or 16 Mbps Token Ring via DB-15 (AUI) connector
■ 4 or 16Mbps Token Ring via RJ-45 connector
Line Interface
■ ISDN BRI, U-interface via RJ-45 connector
■ ISDN BRI, S/T-interface via RJ-45 connector
Modems
■ V.90 or K56flex modems with no external connector required
