Access-Accept Messages
280 Perle 833IS User Guide
Access-Accept Messages
This section describes the attributes which will be accepted by the 833IS from a
RADIUS authentication server in response to an authentication request. The values
returned will override any values currently in use. This includes values derived from
a record in the local user database or from the default user record.
Number Name Description
6 Sevice-Type The type of service to be provided. Supported
values include:
2 = Framed
4 = Callback Framed
6 = Administrative
11 = Callback Administrative
7 Framed-Protocol The link layer protocol to be used by this user.
Supported values include:
1 = PPP
8 Framed-IP-Address The IP address to be assigned to this user.
9 Framed-IP-Netmask The subnet to be assigned to this user.
10 Framed-Routing Indicates how RIPS will be handled if user is
defined as a LAN-to-LAN node. Supported
values include:
0 = None
1 = Send routing packets
2 = Listen for routing packets
3 = Send and listen
11 Filter-ID The name of a filter to be applied to this user.
13 Framed-Compression Compression protocol to be used on the link.
Supported values include:
0 = None
1 = VJ TCP/IP header compression
2 = IPX header compression
19 Callback-Number The number at which the user should be called
back.
