3.
Select
Start
Options
and
press
Enter.
Make
sure
that
Planar
Ethernet
PXE/DHCP
is
set
to
Enabled
.
Select
Startup
Sequence
Options
and
press
Enter;
then,
set
the
PCI
LAN:
Planar
device
as
the
first
startup
device.
4.
Press
Esc
twice
to
exit.
5.
Select
Save
Settings
in
the
Configuration/Setup
Utility
main
menu
and
press
Enter
to
save
your
changes.
Configuring
the
Broadcom
NetXtreme
Gigabit
Ethernet
controller
The
Ethernet
controller
is
integrated
on
the
system
board.
It
provides
an
interface
for
connecting
to
a
10
Mbps,
100
Mbps,
or
1
Gbps
network
and
provides
full
duplex
(FDX)
capability,
which
enables
simultaneous
transmission
and
reception
of
data
on
the
network.
If
the
Ethernet
port
in
the
server
supports
auto-negotiation,
the
controller
detects
the
data-transfer
rate
(10BASE-T,
100BASE-TX,
or
1000BASE-T)
and
duplex
mode
(full-duplex
or
half-duplex)
of
the
network
and
automatically
operates
at
that
rate
and
mode.
You
do
not
have
to
set
any
jumpers
or
configure
the
controller.
However,
you
must
install
a
device
driver
to
enable
the
operating
system
to
address
the
controller.
For
device
drivers
and
information
about
configuring
the
Ethernet
controller,
see
the
Broadcom
NetXtreme
Gigabit
Ethernet
Software
CD
that
comes
with
the
server.
To
find
updated
information
about
configuring
the
controller,
complete
the
following
steps.
Note:
Changes
are
made
periodically
to
the
Lenovo
Web
site.
The
actual
procedure
might
vary
slightly
from
what
is
described
in
this
document.
1.
Go
to:
2.
Enter
your
product
number
(machine
type
and
model
number)
or
select
Servers
and
Storage
from
the
Select
your
product
list.
3.
Select
Servers
and
Storage
from
the
Brand
list.
4.
From
Family
list,
select
ThinkServer
TS100
,
and
click
Continue
.
5.
Click
User's
guides
and
manuals
for
documentation.
LSI
Configuration
Utility
program
Use
the
LSI
Configuration
Utility
program
to
configure
and
manage
redundant
array
of
independent
disks
(RAID)
arrays.
Be
sure
to
use
these
programs
as
described
in
this
document.
v
Use
the
LSI
Configuration
Utility
program
to:
–
Perform
a
low-level
format
on
a
SAS
hard
disk
drive
–
Create
an
array
of
SAS
hard
disk
drives
with
or
without
a
hot-spare
drive
–
Set
SAS
protocol
parameters
on
SAS
hard
disk
drives
The
integrated
SAS/SATA
controller
with
RAID
capabilities
supports
RAID
arrays.
You
can
use
the
LSI
Configuration
Utility
program
to
configure
RAID
1
(IM),
RAID
1E
(IME),
and
RAID
0
(IS)
for
a
single
pair
of
attached
devices.
If
you
install
a
different
type
of
RAID
adapter,
follow
the
instructions
in
the
documentation
that
comes
with
the
adapter
to
view
or
change
SAS
settings
for
attached
devices.
In
addition,
you
can
download
an
LSI
command-line
configuration
program
from
Consider
the
following
information
when
you
are
using
the
LSI
Configuration
Utility
program
to
configure
and
manage
arrays:
