Completing
the
installation
To
complete
the
installation,
you
must
reinstall
the
two-piece
bezel,
reinstall
the
side
cover,
connect
all
the
cables
and,
for
some
devices,
run
the
Configuration/Setup
Utility
program.
Follow
the
instructions
in
this
section.
Reinstalling
the
two-piece
bezel
To
reinstall
the
two-piece
bezel,
complete
the
following
steps:
1.
Install
the
upper
bezel:
a.
Insert
the
two
right-side
tabs
on
the
upper
bezel
into
the
matching
holes
on
the
right
side
of
the
chassis.
b.
Rotate
the
upper
bezel
to
the
left
side
of
the
chassis
and
press
the
bezel
clips
1
into
the
matching
indentations
on
the
left
side
of
the
chassis
until
the
bezel
clips
snap
into
place.
30
ThinkServer
TS100
Types
6431,
6432,
6433,
6434:
Installation
Guide
