Connecting
the
cables
Attention:
To
prevent
damage
to
equipment,
connect
the
power
cords
last.
If
the
server
cables
and
connector
panel
have
color-coded
connectors,
match
the
color
of
each
cable
end
with
the
color
of
the
connector.
For
example,
match
a
blue
cable
end
to
a
blue
connector
on
the
panel,
a
red
cable
end
with
a
red
connector,
and
so
on.
The
following
illustration
shows
the
input/output
(I/O)
connectors
on
the
rear
of
the
server.
Table
10.
Connectors
on
the
rear
of
the
server
1
Ethernet
transmit/
receive
activity
LED
(amber)
8
Serial
1
(Com1)
connector
2
Ethernet
link
status
LED
(green)
9
Parallel
connector
3
Remote
Supervisor
Adapter
II
SlimLine
(Ethernet)
connector
10
Serial
2
(Com2)
connector
4
USB
connectors
1
and
2
11
and
15
DC
power
LED
5
Ethernet
connector
12
and
14
AC
power
LED
6
USB
connectors
3
and
4
13
Power
cord
connector
7
Video
connector
