INSTALLATION
A-3
A-3
VRTEX
TM
360
TECHNICAL SPECIFICATIONS:
AD1332-1 (STD. FREQ.) / AD1332-2 (ALT. FREQ.)
VRTEX™
™
360 - VIRTUAL REALITY WELDING TRAINER
MAKE/MODEL
DESCRIPTION
INPUT VOLTAGE INPUT CURRENT
+/- 10% (MAX.)
AD1332-1
Standard Frequency 115-230 VAC (50-60 HZ) 4A-2A Single Phase
AD1332-2
Alternate Frequency 115-230 VAC (50-60 HZ) 4A-2A Single Phase
INPUT
HEIGHT
WIDTH
DEPTH
WEIGHT
71.0 in.
30.0 in.
50.0 in.
360 lbs.
1803 mm
762 mm
1270 mm
163 kg.
PHYSICAL DIMENSIONS (MACHINE W/MONITOR)
C
1
THIS PRODUCT HAS BEEN TESTED TO THE REQUIREMENTS OF CAN/CSA-C22.2 NO. 61010-1,
2ND EDITION, INCLUDING AMENDMENT 1, OR A LATER VERSION OF THE SAME STANDARD
INCORPORATING THE SAME LEVEL OF TESTING REQUIREMENTS.
HEIGHT
WIDTH
DEPTH
WEIGHT
78.0 in.
39.0 in.
47.0 in.
102 lbs.
1981 mm
990 mm
1194 mm
46 kg.
PHYSICAL DIMENSIONS (STAND)
OPERATING TEMPERATURE RANGE
STORAGE TEMPERATURE RANGE
41
0
- 95
0
F
5
0
- 35
0
C
32
0
- 149
0
F 0
0
- 65
0
C
TEMPERATURE RANGES
80% For Temperatures Up To 88
0
F / 31
0
C
50% @ 104
0
F / 40
0
C
6562 Feet (2000 Meters)
RELATIVE HUMIDITY
OPERATING ALTITUDES
This Product is Pollution Degree 1.
ENVIRONMENT
MAKE/MODEL
DESCRIPTION
OPERATING FREQUENCY
AD1332-1
Standard Frequency
HIGH
AD1332-2
Alternate Frequency
LOW
TRACKING SYSTEM FREQUENCY
WARNING
THIS PRODUCT INCORPORATES A PROTECTIVE EARTH IN THE AC POWER CORD. THE AC PLUG
SHOULD ONLY BE INSERTED INTO A SOCKET OUTLET PROVIDED WITH A
PROTECTIVE EARTH CONTACT.
