INSTALLATION A-2 A-2
VRTEX TM 360
INPUT POWER
ON
OFF
CIRCUIT BREAKER
INPUT POWER
SINGLE PHASE
ALTERNATING CURRENT
READ THIS OPERATORS
MANUAL COMPLETELY
INPUT VOLTAGE
INPUT CURRENT
PROTECTIVE
GROUND
WARNING or CAUTION
Documentation must be con-
sulted in all cases where this
symbol is displayed.
Explosion
Dangerous Voltage
Shock Hazard
GRAPHIC SYMBOLS THAT APPEAR ON
THIS MACHINE OR IN THIS MANUAL
U1
I1
1
Shock Hazard
Return
to
Section
TOC
