OPERATION
B-5
B-5
EAGLE™ 10,000
ARC GOUGING
The EAGLE 10,000 can be used for limited arc goug-
ing.
Set the Range switch to adjust output current to the
desired level for the gouging electrode being used
according to the ratings in the following table:
WELDING PROCESS
For any electrodes the procedures should be kept with-
in the rating of the machine. For electrode information
see the appropriate Lincoln publication.
Stick (Constant Current) Welding
Connect welding cables to the “+” and “-” studs. Start
the engine. The “RANGE” switch markings indicate the
maximum current for that range as well as the typical
electrode size for that range. The “OUTPUT” Control
provides fine adjustment of the welding current within
the select range. For maximum output within a select-
ed range set the “OUTPUT” Control at 10. For mini-
mum output within a selected range set the “OUTPUT”
Control at 5. (“OUTPUT” Control settings below 5 may
reduce arc stability) For best overall welding perfor-
mance set the “RANGE” Switch to the lowest setting
and the OUTPUT” Control near the maximum to
achieve the desired welding current.
RANGE SETTING
TYPICAL
CURRENT RANGE
ELECTRODE SIZE
WIRE FEED WELDING PROCESSES
The Innershield
®
electrode recommended for use with
the EAGLE 10,000 is NR
®
-211-MP. The electrode
sizes and welding ranges that can be used with the
EAGLE 10,000 are shown in the following table:
The EAGLE 10,000 is recommended for limited “MIG”
welding (GMAW - gas metal arc welding). The recom-
mended electrodes are .030” and .035” L-50 and L-56.
They must be used with a blended shielding gas such
as C25 (75% Argon - 25% CO
2
). The welding ranges
that can be used with the EAGLE 10,000 are shown in
the following table:
Diameter
Wire Speed
Approximate
(in.)
Range In./Min.
Current Range
.035
80 - 110
75A to 120A
.045
70 - 130
120A to 170A
.068
40 -
90
125A to 210A
Diameter
Wire Speed
Approximate
(in.)
Range In./Min.
Current Range
.030
75 - 300
50A to 130A
.035
100 - 250
80A to 175A
90 MAX.
145 MAX.
210 MAX.
3/32
1/8
5/32
50 TO 90 AMPS
70 TO 145 AMPS
120 TO 210 AMPS
TIG (CONSTANT CURRENT) WELDING
The K930-[ ] TIG Module installed on a EAGLE 10,000
provides high frequency and shielding gas control for
GTAW (TIG) welding processes. Output Control is from
the Eagle 10,000. The control on the TIG Module is not
functional. After flow time is adjustable from 0 to 55
seconds. A K814 Arc Start Switch is required.
The K930-[ ] TIG Module should be used with the
EAGLE 10,000 on HIGH IDLE to maintain satisfactory
operation. It can be used in the AUTO position but the
delay going to low idle after welding is ceased will be
increased if the AFTER FLOW CONTROL is set above
10 seconds. A K814 Arc Start Switch is required.
Carbon Diameter
CURRENT RANGE (DC+)
1/8
60 - 90 Amps
5/32
90 - 250 Amps
