6
5. LEDs Conditions Definition
5.1 LEDs Defined
The LEDs provide useful information about the switch and the status of all individual ports.
[ For 24+2G fully modulized model ]
LED STATUS CONDITION
Power ON Switch is receiving power.
ON Port has established a valid link. Link / Act
Flashing Data packets being received or sent.
ON The connection is Full Duplex.
OFF The connection is Half Duplex.
FDX / Col
Flashing Collisions happen for half duplex connection
