SKY CMD-
PROGRAMMING A TONE FREQUENCY
On receiving a tone from the Commander, the Transporter
causes the HF transceiver to enter Transmit mode. On
both the Commander and Transporter, access Menu 702
and select the desired, same tone frequency.
CONTROL OPERATION
When in the Sky Command mode, the Microphone keys
of the Commander will function as below. First switch
ON the HF transceiver and press Microphone [0] on the
Commander.
Each time you press the desired key, the Commander
will automatically enter transmit mode and send the
corresponding control command to the Transporter.
Key Function
[1] (PWR) Power ON/ OFF
[2] (RX) HF frequency receive ON/ OFF
[3] (MODE) Modulation mode switch
[4] (RIT) RIT ON/ OFF
[5] (XIT) XIT ON/ OFF
[6] (CLR) RIT offset or XIT offset clear
[7] (SPLIT) Split-frequency ON/ OFF
[8] (M>V) Transfer from Memory to VFO
[9] (A/B)
In VFO mode: VFO A/ VFO B switch
In Memory Recall mode: no change
[0] (SYNC)
Current settings retrieve (from HF
transceiver)
[A] (MONI)
To monitor the UHF band on the
Commander
[B] (M/V) VFO/ Memory Recall mode switch
[C] (UP) XIT/ RIT offset frequency increase
[D] (DOWN) XIT/ RIT offset frequency decrease
[ ] 1 (FAST)
In LSB, USB, or CW mode: 10 Hz/ 1 kHz
switch
In FM or AM mode: 1 kHz/ 10 kHz switch
[#] 2
(ENTER)
In VFO mode: frequency entry ON
In Memory Recall mode: channel number
entry ON
[PTT] To transmit audio on an HF frequency
1 “FS” appears when you select 1 kHz step (LSB/ USB/ CW) or 10 kHz
step (FM/ AM).
2 After pressing Mic [#], press Mic [0] to [9] to enter a frequency or
memory channel number.
Note: To change the frequency or memory channel on the HF
transceiver, rotate the Tuning control.
