SCAN-
PROGRAM SCAN
Program Scan is identical to VFO Scan except that you
select a frequency range for the scan.
n Setting Scan Limits
You can store up to 10 scan ranges in Memory
channels L0/U0 to L9/U9.
1 Press [VFO].
2 Select your desired band.
3 Rotate the Tuning control to select your desired
frequency for the lower limit.
4 Press [F].
• A memory channel number appears and blinks.
5 Rotate the Tuning control to select a channel from
L0 to L9.
6 Press [M.IN] to set the channel number.
• The lower limit is stored in the channel.
7 Rotate the Tuning control to select your desired
frequency for the lower limit.
8 Press [F].
9 Rotate the Tuning control to select a matching
channel number from U0 to U9.
• For example, if you select channel L3 in step 5, select
channel U3 here.
10 Press [M.IN] to set the channel number.
• The upper limit is stored in the channel.
• To confirm the stored scan limits, press [MR],
then select the L and U channels.
Note:
u
The lower limit must be lower in frequency than the upper
limit.
u The lower and upper frequency step sizes must be equal.
u The lower and upper limits must be selected on the same
band.
n Using Program Scan
1 Select your desired band.
2 Press [VFO].
3 Rotate the Tuning control to select a frequency
within your desired scan range.
4 Press [VFO] (1s).
• Scan starts at the current frequency.
• The 1 MHz decimal blinks while scanning is in
progress.
• To reverse the scan direction, turn the Tuning
control clockwise (upward scan) or counterclockwise
(downward scan). You can also press microphone
[UP]/ [DWN].
5 To quit Program Scan, press [VFO] again.
Note:
u
If the step size differs between the lower limit and upper limit,
VFO scan will begin instead of Program Scan.
u If the current VFO frequency is within more than one Program
Scan range, the range stored in the smallest channel number
is used.
MHz SCAN
MHz Scan monitors a 1 MHz segment of the band, using
the current frequency step size. The current 1 MHz digit
determines the limits of the scan. For example, if the
current frequency is 145.400 MHz, then the scan range
would be from 145.000 MHz to 145.995 MHz (the exact
upper limit depends on the current frequency step size).
1 Select your desired band.
2 Press [VFO].
3 Rotate the Tuning control to select a frequency within
your desired 1 MHz range.
4 Press and hold the Tuning control for 1 second to start
scanning.
• Scan starts at the current frequency.
• The 1 MHz decimal blinks while scanning is in progress.
• To reverse the scan direction, turn the
Tuning control
clockwise (upward scan) or counterclockwise (downward
scan). You can also press microphone [UP]/ [DWN].
5 To quit MHz Scan, press the Tuning control again.
CALL SCAN
Use Call Scan to monitor both the Call channel and either
the currently selected VFO frequency or the currently
selected Memory channel.
1 Select your desired VFO frequency or Memory
channel.
2 Press [CALL] (1s) to start Call Scan.
• The 1 MHz decimal blinks while scanning is in progress.
• When scanning a Memory channel, the Call channel on
the same band as the selected Memory channel is used
for scan.
3 To quit Call Scan, press [CALL] again.
Note: The Memory channel selected is scanned even if it has been
locked out of scan.
