Using the Long Roll Accessory
May 2002 D-15
Adjusting the Core Locator Height on the Spindle
The spindles on the Long Roll Accessory have core locators to accommodate
different film sizes.
Push and hold the button to release and position the core locator at the correct
detent. Release the button at the detent you want. The detent positions are:
• 35 mm (top)
• 46 mm
• 120/220 (62 mm)
• 70 mm (bottom; closest to Long Roll Accessory)
P192_1548BC
P192_1548BCA
detent for
35 mm
detent for
46 mm
detent for
120/220 mm
detent for
70 mm
button
core locator
