Page 23
Connecting and Operating the Scanner
May 2002
2-5
Attaching the Cables
CAUTION:
In the next step, avoid forcing the cable pins when plugging the
cable into the scanner. You need a straight-blade screwdriver to
complete the attachment of the cable to the scanner.
1. Attach the Ultra-Wide SCSI cable to the scanner and to the host computer.
The host end of the cable contains ferrite beads.
2. Attach the power cable from the scanner to the power source.
P192_0100HC
power cable
SCSI
cable
ferrite beads
