CAUTION: Use canned or pressurized air to remove any dust or debris
from the connector.
4. Inspect and remove any dust and debris from the connector.
5. Remove the two mounting screws on each side of the connector.
6. Insert the two guide pins in the holes from which you removed the mounting
screws.
7. Tighten the guide pins with a 1/4-in. open-end wrench.
P192_1540BC
P192_1540BCA
2 guide pins
connector
screws
2 mounting
connector
