59 |

CHAPTER 4 – REMOTELY MANAGING YOUR INTERACTIVE WHITEBOARD
SYSTEM

Startup Screen

Selects the type of startup screen to SMART or User.
The SMART screen is the default SMART logo on a
blue background. The User screen uses the saved
picture from the Capture User Startup Screen
function.

Video Mute

Turns the video mute setting On or Off. Select On to
hide the display and Off to show it again.

High Speed Fan

Adjusts the speed of the projector’s fan. Select High
to set the fan to high speed. Select Normal to set the
fan to normal speed.

NOTE
Use the High setting when the projector’s
temperature is high or the altitude is above 6000'
(1829 m).

Projector Mode

Selects the projection mode (Front, Ceiling, Rear or
Rear Ceiling)

IMPORTANT
SMART recommends that you never change this
setting from the Ceiling projection mode.

Source

Selects the input source (VGA1, VGA2, Composite
or S-Video).

VGA1

Assigns an alternative name to your VGA1 input. This
name appears when you select the VGA1 input.

VGA2

Assigns an alternative name to your VGA2 input. This
name appears when you select the VGA2 input.

S-Video

Assigns an alternative name to your S-video input.
This name appears when you select the S-video
input.

Composite

Assigns an alternative name to your composite video
input. This name appears when you select the
composite video input.

Emergency Alert

Turns the on-screen alert broadcast message On or
Off. When enabled, this message displays over the
current projected image.

Alarm Message

Displays an on-screen emergency notification
message (maximum 60 characters).

Submenu Setting

Description
