25 |

CHAPTER 3 – USING YOUR INTERACTIVE WHITEBOARD SYSTEM

Adjustment,
cont’d

H-position

Moves the projected image’s horizontal position left or
right from 0 to 100.

NOTE
Don’t adjust this option unless you’re advised to
by a certified

SMART Technical Support

Specialist

. You can apply these settings only after

you make all boom adjustments. Applies to VGA
inputs only.

V-position

Moves the projected image’s vertical position up or
down from -5 to 5.

NOTE
Don’t adjust this option unless you’re advised to
by a certified

SMART Technical Support

Specialist

. You can apply these settings only after

you make all boom adjustments. Applies to VGA
inputs only.

Saturation

Adjusts the image from black and white to saturated
color from 0 to 100. Applies to S-video and composite
video inputs only.

Sharpness

Adjusts the projected image’s sharpness from 0 to 31.
Applies to S-video and composite video inputs only.

Tint

Adjusts the image color balance of red and green from
0 to 100. Applies to S-video and composite video
inputs only.

White
Peaking

Adjusts the image color brightness from 0 to 10 while
providing more vibrant white shades. A value closer to
0 creates a natural image and a value closer to 10
enhances brightness.

Degamma

Adjusts the color performance of the display from
0 to 3.

Color

Adjusts the Red, Green, Blue, Cyan, Magenta and
Yellow colors on the projector from 0 to 100 to provide
custom color and luminance output. Each color has a
default value of 100. Adjustments to the color settings
register to the User mode.

Menu
Heading

Settings

Description
