Setting the Camera Image and Audio — Camera Menu
42
• When Video output mode (page 33) is set to NTSC +
IP, or PAL + IP and Iris open is Off (page 33), the
output image size is fixed as follows regardless of
settings:
• When Iris open is set to On, the output image size is
fixed at JPEG - 1280 × 960 (Quad-VGA) : MPEG4
- OFF and Light funnel off regardless of settings.
• According to the output image size setting,
superimpose, privacy masking and SolidPTZ have
codec requirements. For details, refer to the following
table.
z Usable – Not usable
With SNC-DS10 / DS60 / CS20
Image size
Select the image size output from the camera with the
following setting:
• JPEG - 768 × 576 : MPEG4 - 640 × 480 (VGA)
• JPEG - 640 × 480 (VGA) : MPEG4 - 640 × 480 (VGA)
• JPEG - 640 × 480 (VGA) : MPEG4 - 384 × 288
• JPEG - 640 × 480 (VGA) : MPEG4 - 320 × 240 (QVGA)
• JPEG - 384 × 288 : MPEG4 - 640 × 480 (VGA)
• JPEG - 320 × 240 (QVGA) : MPEG4 - 640 × 480 (VGA)
• JPEG - 384 × 288 : MPEG4 - 384 × 288
• JPEG - 320 × 240 (QVGA) : MPEG4 - 320 × 240 (QVGA)
Light funnel mode JPEG MPEG4
Light funnel on 640 × 480 (VGA) 640 × 480 (VGA)
Light funnel off 1280 × 960 (Quad-VGA) Off
SolidPTZ Superimpose Privacy masking
JPEG MPEG4 JPEG MPEG4 JPEG MPEG4
JPEG - 1280 × 960 (Quad-VGA) : MPEG4 - OFF : JPEG
cropping available
– – – – z –
JPEG - 1280 × 960 (Quad-VGA) : MPEG4 - OFF – – z – z –
JPEG - 1280 × 960 (Quad-VGA) : MPEG4 - 640 × 480 (VGA) – z – z – z
JPEG - 1280 × 960 (Quad-VGA) : MPEG4 - 384 × 288 – z – z – z
JPEG - 1280 × 960 (Quad-VGA) : MPEG4 - 320 × 240 (QVGA) – z – z – z
JPEG - 960 × 720 : MPEG4 - OFF z – z – z –
JPEG - 768 × 576 : MPEG4 - OFF z – z – z –
JPEG - 640 × 480 (VGA) : MPEG4 - 640 × 480 (VGA) z z z z z z
JPEG - 384 × 288 : MPEG4 - 384 × 288 z z z z z z
JPEG - 320 × 240 (QVGA) : MPEG4 - 320 × 240 (QVGA) z z z z z z
