SBD TANK TYPE HEATERS
SERVICE HANDBOOK
Technical Training Department
Ashland City, TN ©2003
48
SBD MODELS 120 THRU 500A (continued)
SERIES 110-111
CGA
CGA
CGA
CGA
1 ............. Flue Baffle......................................193595...........192199-3 ....... 193795-0 ......... 193696
193795-0
3 ............. Main Burner Orifice Bracket ...........98044(3) ........98044(3) ........ 98044(5).......... 98044(5)
98044(5)
4 ............. Main Burner ...................................98047.............98047 ............ 98047 .............. 98047 98047
5 ............. Main Burner w/Pilot Bracket ...........193873-1 .......193873-1 ....... 193873-1 ......... 193873-1 193873-1
6 ............. Pilot Burner, Natural.......................193314-4 .......193314-4 ....... 193314-4 ......... 193314-4 193314-4
7 ............. Pilot Burner, LP..............................193314-3 .......193314-3 ....... 193314-3 ......... 193314-3 193314-3
CLEANOUT ASSEMBLY
11 ...... Gasket............................................99038.............99038 ............ 99038 .............. 99038 99038
12 ...... Pressure Plate ...............................99037.............99037 ............ 99037 .............. 99037 99037
13 ...... Screws, Self Tapping .....................69852.............69852 ............ 69852 .............. 69852 69852
17 ........... Control, Ignition Module .................193325...........193325 .......... 193325 ............ 193325 193325
18 ........... Control, Dual w/ECO......................192828...........192828 .......... 192828 ............ 192828 192828
19 ........... Cover, Cleanout .............................181260...........181260 .......... 181260 ............ 181260 181260
22a ......... Drafthood .......................................193596...........193596-1 ....... 193596-1 ......... 193596-1 193596-1
22b ......... Damper Drive Assembly ................194484...........194484 .......... 194484 ............ 194484 194484
22c ......... Harness Adapter ............................194459...........194459 .......... 194459 ............ 194459 194459
LABELS
41 ........... Manifold .........................................76244-0 .........76244-0 ......... 76244-2 ........... 76244-2 76244-2
42 ........... Instruction Manual..........................195121-1 .......195121-1 ....... 195121-1 ......... 195121-1 195121-1
43 ........... Main Burner Orifice, Natural...........76243-32 .......76243-30 ....... 76243-35 ......... 76243-32 76243-32
44 ........... Main Burner Orifice, LP..................76243-49 .......76243-46 ....... 76243-51 ......... 76243-49 76243-49
45 ........... Anode Rod .....................................43817-38 .......43817-38 ....... 43817-38 ......... 43817-42 43817-38
47 ........... Transformer ...................................193444...........193444 .......... 193444 ............ 193444 193444
48 ........... Pilot Tubing ....................................1417-60 .........1417-60 ......... 1417-60 ........... 1417-60 1417-60
49 ........... Inlet Tube .......................................193729...........192626 .......... 193729 ............ 192626 193729
51 ........... Gas Valve Natural ..........................192827...........192827 .......... 192827 ............ 192827 192827
52 ........... Gas Valve LP .................................192827-1 .......192827-1 ....... 192827-1 ......... 192827-1 192827-1
55 ........... Switch Panel/Mounting Plate..........193448...........193448 .......... 193448 ............ 193448 193448
56 ........... Off/On Switch.................................193243...........193243 .......... 193243 ............ 193243 193243
57 ........... Bushing ..........................................193404...........193404 .......... 193404 ............ 193404 193404
58 ........... Jumper Wire...................................193476...........193476 .......... 193476 ............ 193476 193476
59 ........... Control Box Panel ..........................193447...........193447 .......... 193447 ............ 193447 193447
60 ........... Cover - Burner ...............................98185.............98185 ............ 98185-2 ........... 98185-2 98185-2
61 ........... Hydro-Cannon................................195100...........195100 .......... 195098 ............ 195098 195098
62 ........... (1 1/2”) galvanized pipe cap ...........193940...........193940 .......... 193940 ............ 193940 193940
63 ........... (1 1/2”) galvanized pipe plug ..........194623...........194623 .......... 194623 ............ 194623 194623
64 ........... (1 1/2”) galvanized pipe union ........194127...........194127 .......... 194127 ............ 194127 194127
CGA CGA CGA CGA CGA
ITEM
PARTS DESCRIPTION SBD71120NE SBD81154NE SBD76180NE SBD85199NE SBD76190N
