F
ORCE 90 ™
90% EFFICIENT
Power-Vent Commercial Gas Water Heater
The 50-gallon, 76,000 BTU Force 90 light-duty commercial gas water heater is equipped with a fully submerged, spiral-shaped condensing heat
exchanger. This design provides much greater heat transfer surface than a standard straight flue tube, resulting in 90% thermal efficiency and
higher hot water output than comparable 80% efficient water heaters. With 22" diameter, the 50-gallon Force 90 can be installed in less space than
a 75-gallon unit and delivers greater recovery and lower operating costs.
Power-Vent Design for Installation Versatility
• Modular blower, with 120 volt, 60Hz electrical system (5 amps or less), 6-foot cord with
standard
3-prong connector
• Combined horizontal and vertical vent runs terminating through outside wall,
using Schedule 40 PVC pipe as follows:
- 2" pipe allows vent runs up to 25 equivalent feet
- 3" pipe allows vent runs up to 65 equivalent feet
- 4" pipe allows vent runs up to 128 equivalent feet
• Supplied with PVC pipe and elbows to connect heat exchanger outlet to blower,
including condensate elbow and drain
• PVC Vent Attenuation Assembly (VAA) supplied to help ensure extra-quiet operation
Side-Mounted Taps for Recirculating Systems
• Hot and cold “side taps” allow Force 90 to be used for “combination” systems
for water heating plus space heating, radiant floor heating or other applications
requiring a recirculating hot water loop
• Plugs for recirculating taps are factory installed
Intelli-Vent
®* Gas Control with Silicon Nitride Hot Surface Ignitor
• Premium-grade hot surface ignitor eliminates standing pilot
• Electronic circuitry provides superior system diagnostic capabilities plus extremely
precise temperature control
• 180°F maximum temperature setting
Glass Lined Tank with Two Magnesium Anode Rods
• Provides superior protection against corrosion
• Glass lining protects all “water side” tank surfaces plus inside of internal heat
exchanger exposed to condensate
Low-NOx Green Choice
® Burner
• Reduces NOx emissions up to 33%, complies with Southern California and Texas
requirements
PEXAN
™ Diffuser Dip Tube
• Helps reduce lime and sediment buildup, maximize hot water output
• PEXAN cross-link polymer withstands long-term exposure to temperatures up to 400°F
Factory-Installed Temperature and Pressure Relief Valve
Maximum Hydrostatic Working Pressure: 150 psi
Meets ASHRAE/IESNA 90.1-1999
• Design-certified by UL (Underwriters Laboratories) according to ANSI Z21.10.3-CSA4.3
standards governing storage-type water heaters
Three-Year Limited Tank Warranty
• Consult written warranty shipped with water heater or contact State for complete
warranty
information
For Additional Technical Information,
PHONE 800-365-0024
State Industries, Inc.
500 Tennessee Waltz Parkway, Ashland City, TN 37015
www.statewaterheaters.com
Page 1 of 2
SCGSS00806
* Intelli-Vent is a registered trademark of the Emerson Electric Company
