DR300 Operator Manual

Data Code

Digit

Position

Designated Item

Designated Description

Field Designation

4 : 2D Bar Code

Field Designation

1 : Data Code

3 Mode

(Format ID)

1 : Numeric Mode
2 : Alpha (upper case mode)
3 : Alphanumeric & Notation
4 : Alphanumeric
5 : 7-bit data
8-bit data mode (*refer to code table)

4, 5
6, 7

Vertical Position

0000: Input only and no printing field
0001 ~ 2848: Vertical position (dot)

8, 9
10

Horizontal Position

001 ~ 640: Horizontal position (dot)

Rotation

0 : 0º
1 : 90º
2 : 180º
3 : 270º

12, 13

Module

01 ~ 32 : Cell Size (dot)
(refer to module size notes)

14, 15

Reserved

16, 17

Error Correction

Error Correction Level
00 : ECC000, 05 : ECC050, 08 : ECC080
10 : ECC100, 14 : ECC140, 20 : ECC200

18 Reserved

[0]

Fixed

19 ~

Reserved

All [0]

* Module
To define the cell size:

1. The definition of 01, 02 dots are acceptable but may face difficulties for

decoding/reading.

2. Use larger module for better printing quality.

Error Correction
To define the error correction level when barcode is damaged or tampered. Connection
level is high with larger correction definition.

Chapter 9 - Online Programming
