DR300 Operator Manual
59
2 : Input Check Designation (Bar Code)
• Bar code without human interpretation character.
• Bar code with human interpretation character,
Digit
Position
Designated Item Designated Description
18, 19, 20 Bar code height 001~600 : bar code height (dot)
21 Reserved 0
22 Sequential
function
0 : No
1 : Increment
2 : Decrement
23, 24 Start Position 01~40 : Starting Position
25, 26 Data Count 01~08 : data count
27, 28, 29 Step (increase,
decrease)
001~999 : sequential step
30, 31 Repeat quantity 01~99 : same number repeat quantity
32-39 Minimum data
range
00000001 ~ 99999999
For incremental numbering, the wrap around value
when it reaches the maximum value.
For decrement numbering, the minimum value.
40-47 Maximum data
range
00000001 ~ 99999999
For incremental numbering, the maximum value.
For decrement numbering, the wrap around value
when it reaches the minimum value.
*Sequential numbering is for numeric data only.
12)
Line / Box Field Transmission
Digit
Position
Designated Item Designated Description
1, 2 Field designation 80 : Line /Box, Graphic, Reverse
3 Font Type 0 : Line / Box
4~7 Vertical Position 0001~1424 : Vertical position (dot)
8~10 Horizontal Position 001~640 : Horizontal position (dot)
11~14 Vertical Line Length 0001~1424 : Vertical line length (dot)
15~17 Horizontal Line
Length
001~640 : Horizontal line length (dot)
18 Horizontal Width 1-9 : Horizontal line thickness (dot)
19 Vertical Width 1-9 : Vertical line thickness (dot)
20~47 Reserved 0 : Reserved
Chapter 9 - Online Programming
