Bar Code Field
1 : Bar code designation
• Bar code without human interpretation character.
• Bar code with human interpretation character.
Digit
Position
Designated
Item
Designated Description
1, 2
Field
designation
70 : Bar code without interpretation (w/o EAN Guide Bar)
71 : Bar code with interpretation (w/o EAN Guide Bar)
72 : Bar code without interpretation (w/EAN Guide Bar)
73 : Bar code with interpretation (w/EAN Guide Bar)
3
Bar code type
0 : NW-7 (Bar ratio selection YES)
1 : CODE 39 (Bar ration selection YES)
2 : INT 2 of 5 (Bar ratio selection YES)
3 : EAN 13 / UPC-A
4 : EAN 8
5 : UPC-E
6 : CODE 128 (B set without control code character)
7 : CODE 128 (C set without control code character)
8 : UCC/EAN 128
9 : BOOKLAND
4, 5
6, 7
Vertical
Position
0000 : Input only and no printing field
001 ~ 1424 : Vertical position (dot)
8-10 Horizontal
Position
001 ~ 640 : Horizontal position (dot)
11
Rotation
0 : 0 degree
1 : 90 degree
2 : 180 degree
3 : 270 degree
12, 13
Character gap
00-99 : Character gap (dot)
(For human interpretation character)
14, 15
Data digits
01~40 : Data digits
*Exclude start/stop code for NW-7, Code 39
*01-20 for Code 128
16
Bar ratio
0 : None (For EAN, etc)
1 : 1:2
2 : 2:5
3 : 1:3
4 : Flexible bar ratio (1 field/format)
5 : Simplified NW-7 (For NW-7 only)
6 : SATOC NW-7 (NW-7 only)
17 Horizontal
expansion
1~9 : Bar code horizontal expansion
