DR300 Operator Manual
56
¾ Input check designation (Normal)
1 Normal, alphanumeric character
Digit
Position
Designated
Item
Designated Description
18 Input check 1 0 : when online mode
19 Input check 2 0 : when online mode
20 Bold Font 0 : None
1 : Right
2 : Lower
3 : Right & Lower
21 Reserved 0
¾ Sequential numbering
1 Normal, alphanumeric character
Digit
Position
Designated Item Designated Description
22 Sequential function 0 : No
1 : Increment
2 : Decrement
23, 24 Start Position 01~40 : starting position
25, 26 Data Count 01~08 : data count
27, 28,
29
Step (increase, decrease) 001~999 ; sequential step
30, 31 Repeat quantity 01~99 : same number repeat quantity
32-39 Minimum data range 00000001~99999999 :
For incremental numbering, the wrap
around value when it reaches the
maximum value.
For decrement numbering, the minimum
value.
40-47 Maximum data range 00000001~99999999
For incremental numbering, the
maximum value.
For decrement numbering, the wrap
around value when it reaches the
minimum value.
* Sequential numbering is for numeric data only.
Chapter 9 - Online Programming
