DR300 Operator Manual
48
4) Media Parameter Transmission
This command designates paper size, base reference position, sensor type, etc.
[1BH, 4DH] n n n…..
E
Size
Base reference
Paper
Vertical
position
Horizontal
position
E
Copy Image
Rotate Print
S M Designation
position
designation Information adjustment adjustment
J
designation designation
C
E
C
T
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23
Digit Position
Item
Data
Description
1 – 3
Size designation
nnn Designates paper size for printing with mm unit.
4
Base reference position
(Direction)
n
Shows moving direction of base position for print and
cut.
1 : + towards feeding direction
0 : - towards feeding direction
5 – 7
Base reference position
designation (Movement)
nnn Designates movement of base position for print and cut
in dot unit.
8
Paper Information (Kind
of paper)
n
Label = 0, Tag = 1
9 Paper
Information
(Sensor)
n
Centre hole = 1
I-mark = 2 } Designates paper identifying
Gap = 3 } sensor
Side hole = 4 }
10
Paper Information (Cut
function)
n
Cut function OFF = 0, ON = 1
11 Vertical
position
Adjustment (Direction)
+ , - From top of print, DOWN = +, UP = -
12 , 13
Vertical position
Adjustment
(Movement)
nn
Value in dot unit
14 Horizontal
position
Adjustment (Direction)
+ , - From top of print, RIGHT = +, LEFT = -
15 , 16
Horizontal position
Adjustment
(Movement)
nn
Value in dot unit
17
Eject Cut
n
Eject function, OFF = 0, ON = 1
18
Image Copy (ON/OFF)
n
Image print OFF = 0, ON = 1
19 , 20
Image Copy
(Movement)
nn
Designates sideway movement in mm unit
21 Rotate
(ON/OFF)
n
Rotate print OFF = 0, ON = 1
22 , 23
Rotate print
(Paper Width)
nn
Designates width of paper used in mm unit.
Chapter 9 - Online Programming
